12R(Curve)

Product feature
Product Specifications
Detail Pictures of Product

Product Catalog About Commercial Displays

Product Specifications

12R(Curve) Series Gaming MonitorDifference contrast

Model W3212RUC W3212REC Q3212RVC Q2712RVC

Panel size 32" 32" 32" 27"

Display parameters Backlight category ELED edge Type ELED edge Type ELED edge Type ELED edge Type
Panel VA Curved 1500R VA Curved 1500R Fast VA Curved 1500R Fast VA Curved 1500R
Aspect ratio 16:9 16:9 16:9 16:9
Color Gamut 95%DCI-P3 95%DCI-P3 95%DCI-P3 95%DCI-P3
Resolution 1920*1080 1920*1080 2560*1440 2560*1440
Resfresh rate 165Hz 240Hz 180Hz 180Hz
Viewing angle H:178°/V:178° H:178°/V:178° H:178°/V:178° H:178°/V:178°
Brightness 350cd/m² 350cd/m² 300cd/m² 300cd/m²
Contrast ratio 3500:1 3500:1 3500:1 5000:1
Response time 1ms(MRPT) 1ms(MRPT) 1ms 2ms

Specifications VESA Wall Mount 100mm*100mm 100mm*100mm 100mm*100mm 100mm*100mm

Input Interface HDMI 2 2 2 2
DP 1 1 2 2
USB / / 1 1
Type-C / / / /

Output Interface Earphones 1 1 1 1

Special Functions Flicker-free Support Support Support Support
Blue-light filtering Support Support Support Support
HDR Support Support Support Support
Freeysnc Support Support Support Support
G-sync compatible Support Support Support Support

Model W2712RVC W2712RFC W2412RV W2412RG

Panel size 27" 27" 24" 24"

Display parameters Backlight category ELED edge Type ELED edge Type ELED edge Type ELED edge Type
Panel Fast VA Curved 1500R Fast VA Curved 1500R Fast VA Curved 1500R VA Curved 1500R
Aspect ratio 16:9 16:9 16:9 16:9
Color Gamut 95%DCI-P3 95%DCI-P3 72%NTSC 72%NTSC
Resolution 1920*1080 1920*1080 1920*1080 1920*1080
Resfresh rate 180Hz 280Hz 180Hz 100Hz
Viewing angle H:178°/V:178° H:178°/V:178° H:178°/V:178° H:178°/V:178°
Brightness 300cd/m² 400cd/m² 250cd/m² 250cd/m²
Contrast ratio 4000:1 3000:1 3000:1 3000:1
Response time 2ms 1ms 1ms 5ms

Specifications VESA Wall Mount 100mm*100mm 100mm*100mm 100mm*100mm 100mm*100mm

Input Interface HDMI 2 2 2 1
DP 1 2 1 1
USB / 1(Only for Upgrade) / /
Type-C / / / /

Output Interface Earphones 1 1 1 1

Special Functions Flicker-free Support Support Support Support
Blue-light filtering Support Support Support Support
HDR Support Support Support Nonsupport
Freeysnc Support Support Support Support
G-sync compatible Support Support Support Support

Remarks: KTC will provide the information as correct as possible. Product photos on this website may vary from the real products. Products information may vary from the products manual available in the market. Please use the products subjected to the specific information on the user manual. For details, please contact the related persons.
